The SPEAR-22 is an underdevelopment advanced loitering muniton drone specifically designed for long-range and extended endurance operatons. It features a unique high dihedral, tandem wing configurattion that contributes to its aerodynamic efficiency and stability in various flight conditons.
With an impressive endurance of up to 90 minutes and a maximum range of up to 120 km, this aircraft is well-suited for extended recon- naissance, surveillance, and strike missions. The SPEAR-22 boasts asubstantal payload capacity of up to 15 kg, allowing for the integra- ton of various sensors, communicatiion systems, or munitons based on mission requirements.
Weighing 25 kg when empty, the SPEAR-22 has a wingspan of 3.15 meters and a length of 2.4 meters when folded, ensuring a compact yet robust design that can withstand the rigors of demanding oper- atiional environments. The drone's modular design facilitates easy maintenance, rapid deployment, and adaptability for various mission profiles, making it a versatile and invaluable asset for modern military and security forces.
Maximum take-off weight 40 kg
Payload up to 15 kg
Cruise Speed 80–140 km/h
Endurance 45–90 min
Range 60–120 km
Wingspan 3.15 m
Width 0.45 m Folded
Height 0.33 m
Length 2.16 m deployed – 2.44 m folded
Warhead Multi-purpose and-personnel/anti-armour/combined
ISR missions for target detection, recognition, identification and classification
